S22P115.5 - Positive Meniscus Lens

Stock Quantity：50In stock, 5-10 days

Please contact us if you are interested

￥ 130

Quantity:1-9

￥ 115

Quantity:10-20

￥ 100

Quantity：>20

The most value！

Quantity:

The detailed specification Download

Package Number:
S22P115.5

Material:
H-ZF7LA
Diameter 1（mm）:
22

Diameter Tolerance 1:
+0.0/-0.1
Radius R1（mm）:
29.753

Radius R2（mm）:
42.17
Center Thickness（mm）:
2.4

Thickness Tolerance:
±0.1
Power (P-V):
3

Irregularity (P-V):
0.5
Coating Specification:
AR@1465-1615nm

Surface Quality:
60-40
Centering (arcmin):
1′

Clear Aperture:
95%
Effective Focal Length（F')（mm）:
115.50

Focal Length Tolerance:
±1%
F' Specification Wavelength:
587.6nm

Blacking:
否
SAG 1
/

SAG Tolerance:
/

Download

PDF Drawing Zemax
